Ecostar
HP + Gas Burners
ECO 11000 HP G C3+
- Enhanced combustion efficiency with Low NOx and CO emissions,
- Compatibility with the combustion chamber via adjustable flame formation,
- Modulating operation,
- Operation with natural gas and LPG fuels,
- Operation at gas pressures of 500 mbar and 21 mbar,
- Wide thermal capacity adjustment range according to heat demand,
- Reliable operation thanks to the pilot ignition system,
- Flame monitoring with ignition and ionization electrodes,
- Monitoring of sufficient gas pressure with the minimum gas pressure switch,
- Uniform fuel-air mixture with a specially designed combustion head providing high combustion efficiency,
- Monitoring of combustion air with the air pressure switch,
- Minimum friction losses in the burner body and combustion head,
- Easy access to all components without removing the burner from the boiler,
- Compact design requiring minimum maintenance,
- Environmentally friendly with low NOx and CO emissions,
- Lower noise level with a specially designed silencer system,
- Easy maintenance with a hinged system without the need to separate the burner from the boiler,
- Low-noise operation thanks to the specially designed burner.
| Burner Type | Capacity | Capacity | Natural Gas Consumption | LPG Consumption | Fan Motor Power | Voltage at 50 Hz | Air Intake Type | Body | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min. kcal/h | Max. kcal/h | Min. kW | Max. kW | Min. Nm³/h | Max. Nm³/h | Min. Nm³/h | Max. Nm³/h | kW | VAC | |||
| ECO 11000 HP G C3+ | 946.000 | 9.460.000 | 900 | 11.000 | 115 | 1.147 | 42 | 420 | 22 | 3N 400 | Sheet Metal | Sheet Metal |
|
* Low Calorific Value: LCV Natural Gas : 8250 kcal /Nm³ , LCV LPG : 22500 kcal /Nm³ |
||||||||||||
